High Frequency customed：6-8 dB, 0.5-26.5 GHz； 10-16 dB, 0.5-26.5 GHz； 20 dB, 0.5-26.5 GHz； 30 dB, 0.5-26.5 GHz Spot Goods Model：（The products have large inventory below, please contact us directly。） |
|
Model |
Freq.MHz |
Ins.LossdB |
coupled factor dB |
directionalitydB |
VSWR |
power handling (w) |
impedance(Ω) |
Connector |
operating temperature(℃) |
|
OCP800-2500-5 |
800-2500 |
2 |
-5 |
20 |
1.3 |
100 |
50 |
N-50K |
-30~+70 |
|
OCP800-2500-6 |
800-2500 |
1.8 |
-6 |
20 |
1.3 |
100 |
50 |
N-50K |
-30~+70 |
|
OCP800-2500-7 |
800-2500 |
1.4 |
-7 |
20 |
1.3 |
100 |
50 |
N-50K |
-30~+70 |
|
OCP800-2500-10 |
800-2500 |
0.8 |
-10 |
20 |
1.3 |
100 |
50 |
N-50K |
-30~+70 |
|
OCP800-2500-15 |
800-2500 |
0.4 |
-15 |
20 |
1.3 |
100 |
50 |
N-50K |
-30~+70 |
|
OCP800-2500-20 |
800-2500 |
0.2 |
-20 |
20 |
1.3 |
100 |
50 |
N-50K |
-30~+70 |
|
OCP800-2500-25 |
800-2500 |
0.2 |
-25 |
20 |
1.3 |
100 |
50 |
N-50K |
-30~+70 |
|
OCP800-2500-30 |
800-2500 |
0.2 |
-30 |
20 |
1.3 |
100 |
50 |
N-50K |
-30~+70 |
|
OCP800-2500-40 |
800-2500 |
0.2 |
-40 |
20 |
1.3 |
100 |
50 |
N-50K |
-30~+70 |
